Frame is designed with endurance positioning and shorter chainstays for precise handling, agility and control. A longer reach, shorter stem and lower bottom bracket drop improves stability on rugged terrain.

Tuned compliance

Dropped seatstays with thin tubing absorb road shocks and vibrations. The D-Fuse handlebar and seatpost work as a system to add compliance without sacrificing stiffness while cornering, sprinting or climbing.

Adaptable to the terrain

A flip chip on the rear dropout adjusts the wheelbase: short for quicker handling and acceleration, or long for improved stability at speed. The long setting allows for larger diameter tires up to 53mm. You can choose the included D-Fuse seatpost for maximum compliance, or switch to a 30.9mm round or dropper post.

SPECIFICATIONS

• Frame: ALUXX-grade aluminum, 12x142mm thru-axle, disc, flip chip dropout
• Fork: Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc
• Handlebar: Giant Contact XR D-Fuse, 31.8mm XS:42cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
• Handles: cork tape with gel
• Gallows: Giant Contact, 8-degree XS:50mm, S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm
• Seat post: Giant D-Fuse, alloy, 14mm offset
• Saddle: Giant Grit
• Gear levers: Shimano GRX RX-610, 2x12
• Front derailleur: Shimano GRX RX-820
• Rear derailleur: Shimano GRX RX-820
• Brakes: Shimano GRX RX-410 hydraulic, Giant MPH rotors [F]160mm, [R]160mm
• Brake levers: Shimano GRX RX-610 hydraulic
• Cassette: Shimano 105, 11x34
• Chain: KMC X12L-1
• Crankset: Shimano FC-RX610-2, 30/46
• Bottom bracket: Shimano, threaded
• Rims: Giant S-X2, alloy
• Hubs: Giant alloy, 12mm thru-axle
• Rays: stainless
• Tires: Giant Crosscut Grip 1, tubeless, 700x40c, 60TPI, folding
• Extras: tubeless prepared, 53mm max tire size in "long" flip chip position, 45mm max tire size in "short" flip chip position
• Max Tire Clearance: 53mm
