PRODUCT OVERVIEW

The mountain bike experience starts here. With a redesigned frame that's now lighter and more durable, along with a smooth-riding suspension form, thru-axle hubs*, and a 1X drivetrain*, this aluminum hardtail is everything an aspiring MTB rider needs to evolve and advance. ***NOT AVAILABLE TO SHIP. LOCAL PICK UP ONLY***

Features

• Modern MTB Design - Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models
• Off-Road Control - New geometry is optimized for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size. All models have clearance for high-volume tires (up to 2.4-inch) for traction and grip on technical terrain.
• Light and Durable - All-new ALUXX aluminum frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.

SPECIFICATIONS

• Frame: ALUXX-grade aluminum, disc
• Fork: SR Suntour XCE, QR, steel steerer, XS, S: 80mm travel (27.5), S, M, L, XL, XXL:100mm travel (29)
• Shock: N/A
• Handlebar: Giant Connect Trail, 31.8mm
• Grips: Giant Sole-O
• Stem: Giant Sport, 7-degree
• Seatpost: Giant Sport, 30.9
• Saddle: Giant ErgoContact Trail
• Pedals: platform
• Shifters: microSHIFT Acolyte, 1x8
• Front Derailleur: N/A
• Rear Derailleur: microSHIFT Acolyte, RD-M5185M with clutch
• Brakes: Tektro TKB-172, mechanical, [F]160mm, [R]160mm rotors
• Brake Levers: Tektro RS360A
• Cassette: microSHIFT Acolyte, 8-speed, 12x46
• Chain: KMC 8.1
• Crankset: ProWheel, [27.5] 32t, [29] 30t, 52.5mm chainline 32t
• Bottom Bracket: cartridge
• Rims: Giant GX03V 27.5 or 29, alloy, double wall, 21mm IW
• Hubs: alloy, sealed bearing, [F] 9mm QR, [R] 12x142 thru-axle
• Spokes: stainless
• Tires: Maxxis Ikon 27.5x2.2 or Maxxis Ikon 29x2.2, 60 TPI, wire bead
• Extras: 2.4" max tire size, max chainring 32t
